Minimum der Bestellmenge:1 Piece/Pieces
Modell: G121EAN01.2
Hochhellige LCD -Display SerieStunlight lesbarhas Das Patent des ultra -Dünnstruktur -Designs und der fortschrittlichen Technologie der Bildqualität.
500-5000Nit Helligkeitsanpassung, genaue Kontrolle der Helligkeit jedes Bereichs.
| brand | AUO | Model name | G121EAN01.2 |
| size | 12.1" | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1280(RGB)×800 (WXGA) 124PPI | Pixel configuration | RGB vertical bar |
| Display size | 261.12 × 163.2 (H×V) mm | Appearance of size | 278×184×9.94((H×V×D) mm |
| Visual size | 264.22 × 168.12 (H×V) mm | Surface treatment | Mist side，Hard coating (3H) |
| Brightness(cd/m²) | 1000 cd/m² (Typ.) | contrast | 1000 : 1 (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Apply to | Industrial and outdoor highlighting |
| Signal system | 30 pins LVDS (1 ch, 6/8-bit) , terminal | ||
| Maximum rated | Storage temperature: -30 ~ 85 °C Working temperature: -30 ~ 85 °C |
Hot -Tags: 12.1 "Auo G121EEN01.2 TFT LCD -Modul, China, Fabrik, billig, preis, angepasst, Angebot, Fensterausstattung LCD, 55 -Zoll Anzeigen von Bildschirmen, Sonnenlicht -lesbarer LCD -Display
