Minimum der Bestellmenge:1 Piece/Pieces
Size: 10.1 inch
Brightness: 1000 nits
Contrast Ratio: 1000:1
Resolution: 1280*800
Operating Temperature: -10 - 50°C
Kleine Größe eingebettete Außendisplays, 10,1 Zoll TFT 1000 Nits LCD -Monitor. Der auf dem Bildschirm angezeigte Inhalt ist deutlich in einer gut beleuchteten Umgebung zu sehen, kann mit allen Arten von Ladepfählen, Selbstbedienungsbetragsautomaten, Kiosken und anderen Serverklemmen verwendet werden.
Wenn Sie andere Bedürfnisse haben, kontaktieren Sie uns bitte an uns, die am besten geeignete Flüssigkeitskristall -Display -Lösung entsprechend Ihren Anforderungen.
Eingebettete Produktfunktion im Freien Displays
10.1 "TFT LCD -Panel
1280*800 Auflösung
im Freien verwendet, die Helligkeit von 500 Nits bis 1500 Nits optional
Kapazitiver Touchpanel, mit 2 mm geschmittertem Glas fest und zuverlässig für Vandal -Beweis
VGA HDMI DVI USB -Schnittstelle
Hochleistungs -Mainboard, 7/24 kontinuierlicher Betrieb
Unterstützung von 12-24 V Weitspannung
Ultra-dünne vordere Lünette 3 mm, ideal für die eingebettete Montage
Frontplatte IP55 wasserdichte Staubverhütung
Großtemperaturbetrieb: -10 - 50 ° C
Product specification |
|
LCD panel |
|
Panel size |
10.1" |
Resolution |
1280*800 or 1024*600 |
Support Color |
16.7M colors |
Brightness (cd/m²) |
1000 nits (can be customized) |
Contrast ratio |
1000:1 |
View angle |
80°/80°/80°/80° (R/L/U/D) |
Touch panel |
|
Touchscreen Type |
Capacitive Touch (10 points ) |
Surface Hardness |
7H |
Luminousness |
90% |
Touch Interface |
USB (RS232 optional) |
Touch response time |
2ms |
Working Life |
>50 million times |
OSD |
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
Support OS |
Windows ,HDMI, Android, ect. |
Power Supply |
|
External Power Supply |
AC 100 - 240V, 50-60Hz |
Working voltage |
DC 12-24V |
Power consumption |
≤35W |
Enclosure |
|
Material |
Aluminum Alloy |
Color |
Black, Silver or customized |
VESA mounting |
75x75mm/100x100mm |
IP grade |
Front panel IP55 waterproof |
Operating Environment |
|
Temperature Range |
operating: -10 to 50°C, storage: -20 to 80°C |
Relative humidity |
operating: -5% to 95%, storage: -5% to 95% |
Packing Details |
|
Gross weight |
about 4kg |
Accessories |
Power adapter, VGA cable, USB touch cable, embedded screws |
Other |
|
Mounting |
embedded mounting screws |
wall mounting brackets (optional) |
|
desk stand holder (optional) |
|
Warranty |
1 year warranty |
Certificates |
CE, 3C, RoHS |
