Minimum der Bestellmenge:1 Piece/Pieces
1000Nits High Bright Touch-Modul, skalierbar in Größe (von 10,1 "bis 27"), kostengünstiges, hohes Hell-Touch-Modul mit Vielseitigkeit und Funktionalität für eingebettete Anwendungen, die eine eindeutige Lösung für alle Client-Anforderungen formen.
1000Nits High Bright Touch-Modul können eingebettete, eingebettete Clips, Vesa, Wandmontage-Kit, Desktop-Ständer, Falthalter sowie eine Vielzahl von Touch-Technologien, einschließlich P-CAP, Resist und IR entsprechend Ihren Anforderungen, ausgewählt.
Features |
1. Integrated solution for touch function and LCD display |
2. USB touch interface for flexible customer selection |
3. Long product life cycle, upgrade or replacement of LCD screen will not cause external dimensional changes |
4. High brightness, high contrast, fast response time, multi-color support, wide viewing angle |
5.A variety of mounting options, including horizontal mounting bracket mounting, vertical mounting bracket mounting, VESA standard mounting, and customer self-designed mounting |
6.Capacitive touch for a stable and sensitive touch experience and high-definition visual enjoyment |
7.Can adapt to various customization requirements of customers |
Product specification | |
LCD panel | |
Panel size | 10.1/13.3/15/15.6/17 /18.5/19/21.5/23.6/27inch |
Support Color | 16.7M colors |
Brightness (cd/m²) | 1000 nits (can be customized) |
Touch panel | |
Touchscreen Type | Capacitive Touch (10 points ) |
Surface Hardness | 7H |
Luminousness | 90% |
Touch Interface | USB (RS232 optional) |
Touch response time | 2ms |
Working Life | >50 million times |
OSD | |
Support OS | Windows ,HDMI, Android, ect. |
Power Supply | |
External Power Supply | AC 100 - 240V, 50-60Hz |
Working voltage | DC 12-24V |
Power consumption | ≤35W |
Enclosure | |
Material | Aluminum Alloy |
Color | Black, Silver or customized |
VESA mounting | 75x75mm/100x100mm |
Operating Environment | |
Temperature Range | operating: -10 to 50°C, storage: -20 to 80°C |
Relative humidity | operating: -5% to 95%, storage: -5% to 95% |
